What we make

Product Showcase

Every board is designed for a specific job. No compromises, no unnecessary complexity. Here's what we currently offer — and remember, every board can be customised.

FLAGSHIP
VE-PWR-16 MAIN CONTROLLER FET FET FET FET FET FET

PWR-DIST-16 Series

16-Channel Power Distribution Module

Our flagship power distribution board, designed for full-size campervans and motorhomes with complex electrical demands. The PWR-DIST-16 replaces a tangle of fuse holders, relays, and manual switches with a single intelligent module — fully controllable via CAN-bus, Bluetooth app, or hardwired inputs.

  • ✓16 independently switched output channels (12V, 24V or 48V configurable)
  • ✓Per-channel current monitoring and overcurrent protection (1–30A per channel)
  • ✓CAN-bus 2.0B and UART interfaces for integration with BMS and inverters
  • ✓Bluetooth Low Energy module with companion iOS/Android app
  • ✓Configurable load-shedding priority profiles for low battery scenarios
  • ✓Built-in temperature monitoring and thermal shutdown
  • ✓Conformal coated, IP67 enclosure option available
12–48V DC 16 channels Max 480A total CAN-bus BLE 5.0 -40°C to +85°C CE / UKCA
COMPACT
VE-BMS-8S BATTERY MONITOR 100mΩ 100mΩ

VE-BMS-8S Series

8S Battery Management System Interface

The VE-BMS-8S bridges your LiFePO₄ or lithium battery pack to the rest of your van's electrical system. It monitors cell voltage, pack temperature, and state-of-charge in real time, triggering protection events before any damage occurs. Compact enough to fit anywhere in your battery bay.

  • ✓Supports 2S–8S lithium chemistries (LiFePO₄, NMC, LTO)
  • ✓Precision coulomb counting for accurate SoC to ±1%
  • ✓Cell balancing — passive up to 100mA per cell
  • ✓Over-voltage, under-voltage, over-current, and over-temperature protection
  • ✓UART / CAN / RS485 output — connects directly to PWR-DIST-16
  • ✓Compact 110 × 70mm form factor
2S–8S cells Up to 300A ±1% SoC CAN / UART 110×70mm CE / UKCA
CUSTOM
SOLAR IN/MPPT VE-SOLAR-30 CHARGE CONTROLLER INDUCTOR FET FET

VE-SOLAR-30 Series

30A MPPT Solar Charge Controller

A purpose-built solar charge controller with MPPT tracking specifically designed for campervan roof installations. Unlike generic charge controllers, the VE-SOLAR-30 is native to the VoltEdge ecosystem — it communicates directly with our PWR-DIST and BMS modules for a fully unified system.

  • ✓30A MPPT solar charge controller (up to 450W panel input)
  • ✓Multi-stage adaptive charging profiles (Bulk/Absorb/Float/Equalise)
  • ✓Compatible with all lithium and lead-acid battery types
  • ✓Native VoltEdge protocol for ecosystem integration
  • ✓Real-time solar harvest logging via companion app
  • ✓Dual solar input for multiple panel strings
  • ✓Load output with programmable dusk/dawn switching
30A MPPT 12/24/48V auto 450W max input Dual string 98% efficiency CE / UKCA

Don't see what you need?

We do fully custom boards

Have a specific requirement? We take on bespoke design commissions. Tell us your voltage, channels, protocol and mounting constraints and we'll engineer it from scratch.

Start a custom enquiry →
